The VP 1500 Bin Unloader is designed from the transfer of billets or other pieces from a pallet bin. The weight of each single piece cannot exceed 5kg/pc. Using a forklift or pallet jack, the operator places the pallet bin with billets into the bin unloader recieving frame. Pushing a button activates the rotation of the bin, causing the billets to fall out.
| Dimensions W x D x H | Pallet [mm] | 1200 x 800 x 600 |
| Bin Unloader [mm] | 2411 x 1380 x 2288 | |
| Maximum Weight Load (including pallet) [kg] | 1500 | |
| Maximum Piece Weight [g] | 5 | |
| Bin Unloader Overall Weight [kg] | 1200 | |
